PDF Reference sixth edition, Adobe Portable Document Format Version 1.7 (book 1) — page 2

CHAPTER 2

Overview

Macintosh application

Windows application

QuickDraw/

GDI

CoreGraphics

Adobe PDF

printer

PDF

Acrobat

FIGURE 2.1 Creating PDF files using the Adobe PDF printer

Instead of describing their printable output through API calls, some applications

produce PostScript page descriptions directly—either because of limitations in

the QuickDraw or GDI imaging models or because the applications run on plat-

forms such as DOS or UNIX^®, where no system-level printer driver exists. Post-

Script files generated by such applications can be converted to PDF files using the

Acrobat Distiller^® application (see Figure 2.2). Because PostScript and PDF share

the same Adobe imaging model, Distiller can preserve the exact graphical con-

tent of the PostScript file in the translation to PDF. Additionally, Distiller sup-

ports a PostScript language extension, called pdfmark, that allows the producing

application to embed instructions in the PostScript file for creating hypertext

links, logical structure, and other interactive and document interchange features

of PDF. Again, the resulting PDF file can be viewed with a viewer application,

such as Acrobat, on any supported platform.

SECTION 2.4

PDF and the PostScript Language

PostScript

page description

Acrobat Distiller

PDF

Acrobat

FIGURE 2.2 Creating PDF files using Acrobat Distiller

2.4

PDF and the PostScript Language

The PDF operators for setting the graphics state and painting graphics objects are

similar to the corresponding operators in the PostScript language. Unlike Post-

Script, however, PDF is not a full-scale programming language; it trades reduced

flexibility for improved efficiency and predictability. PDF therefore differs from

PostScript in the following significant ways:

• PDF enforces a strictly defined file structure that allows an application to ac-

cess parts of a document in arbitrary order.

• To simplify the processing of content streams, PDF does not include common

programming language features such as procedures, variables, and control con-

structs.

• PDF files contain information such as font metrics to ensure viewing fidelity.

• A PDF file may contain additional information that is not directly connected

with the imaging model, such as hypertext links for interactive viewing and

logical structure information for document interchange.

Because of these differences, a PDF file generally cannot be transmitted directly

to a PostScript output device for printing (although a few such devices do also

CHAPTER 2

Overview

support PDF directly). An application printing a PDF document to a PostScript

device must follow these steps:

1. Insert procedure sets containing PostScript procedure definitions to implement

the PDF operators.

2. Extract the content for each page. Each content stream is essentially the script

portion of a traditional PostScript program using very specific procedures,

such as m for moveto and l for lineto.

3. Decode compressed text, graphics, and image data as necessary. The compres-

sion filters used in PDF are compatible with those used in PostScript; they may

or may not be supported, depending on the LanguageLevel of the target output

device.

4. Insert any needed resources, such as fonts, into the PostScript file. These can

be either the original fonts or suitable substitute fonts based on the font met-

rics in the PDF file. Fonts may need to be converted to a format that the Post-

Script interpreter recognizes, such as Type 1 or Type 42.

5. Put the information in the correct order. The result is a traditional PostScript

program that fully represents the visual aspects of the document but no longer

contains PDF elements such as hypertext links, annotations, and bookmarks.

6. Transmit the PostScript program to the output device.

CHAPTER 3

Syntax

This chapter covers everything about the syntax of PDF at the object, file, and

document level. It sets the stage for subsequent chapters, which describe how the

contents of a PDF file are interpreted as page descriptions, interactive

navigational aids, and application-level logical structure.

PDF syntax is best understood by thinking of it in four parts, as shown in Figure

3.1:

• Objects. A PDF document is a data structure composed from a small set of

basic types of data objects. Section 3.1, “Lexical Conventions,” describes the

character set used to write objects and other syntactic elements. Section 3.2,

“Objects,” describes the syntax and essential properties of the objects. Section

3.2.7, “Stream Objects,” provides complete details of the most complex data

type, the stream object.

• File structure. The PDF file structure determines how objects are stored in a

PDF file, how they are accessed, and how they are updated. This structure is

independent of the semantics of the objects. Section 3.4, “File Structure,” de-

scribes the file structure. Section 3.5, “Encryption,” describes a file-level mech-

anism for protecting a document’s contents from unauthorized access.

• Document structure. The PDF document structure specifies how the basic ob-

ject types are used to represent components of a PDF document: pages, fonts,

annotations, and so forth. Section 3.6, “Document Structure,” describes the

overall document structure; later chapters address the detailed semantics of the

components.

• Content streams. A PDF content stream contains a sequence of instructions de-

scribing the appearance of a page or other graphical entity. These instructions,

while also represented as objects, are conceptually distinct from the objects that

CHAPTER 3

Syntax

represent the document structure and are described separately. Section 3.7,

“Content Streams and Resources,” discusses PDF content streams and their as-

sociated resources.

Objects

File

Content

structure

stream

Document

structure

FIGURE 3.1 PDF components

In addition, this chapter describes some data structures, built from basic objects,

that are so widely used that they can almost be considered basic object types in

their own right. These objects are covered in Sections 3.8, “Common Data

Structures”; 3.9, “Functions”; and 3.10, “File Specifications.”

PDF’s object and file syntax is also used as the basis for other file formats. These

include the Forms Data Format (FDF), described in Section 8.6.6, “Forms Data

Format,” and the Portable Job Ticket Format

(PJTF), described in Adobe

Technical Note #5620, Portable Job Ticket Format.

3.1

Lexical Conventions

At the most fundamental level, a PDF file is a sequence of 8-bit bytes. These bytes

can be grouped into tokens according to the syntax rules described below. One or

more tokens are assembled to form higher-level syntactic entities, principally

objects, which are the basic data values from which a PDF document is

constructed.

PDF can be entirely represented using byte values corresponding to the visible

printable subset of the ASCII character set, plus white space characters such as

space, tab, carriage return, and line feed characters. ASCII is the American

Standard Code for Information Interchange, a widely used convention for

SECTION 3.1

Lexical Conventions

encoding a specific set of 128 characters as binary numbers. However, a PDF file

is not restricted to the ASCII character set; it can contain arbitrary 8-bit bytes,

subject to the following considerations:

• The tokens that delimit objects and that describe the structure of a PDF file are

all written in the ASCII character set, as are all the reserved words and the

names used as keys in standard dictionaries.

• The data values of certain types of objects—strings and streams—can be but

need not be written entirely in ASCII. For the purpose of exposition (as in this

book), ASCII representation is preferred. However, in actual practice, data that

is naturally binary, such as sampled images, is represented directly in binary for

compactness and efficiency.

• A PDF file containing binary data must be transported and stored by means

that preserve all bytes of the file faithfully; that is, as a binary file rather than a

text file. Such a file is not portable to environments that impose reserved char-

acter codes, maximum line lengths, end-of-line conventions, or other restric-

tions.

Note: In this chapter, the term character is synonymous with byte and merely refers

to a particular 8-bit value. This usage is entirely independent of any logical meaning

that the value may have when it is treated as data in specific contexts, such as repre-

senting human-readable text or selecting a glyph from a font.

3.1.1

Character Set

The PDF character set is divided into three classes, called regular, delimiter, and

white-space characters. This classification determines the grouping of characters

into tokens, except within strings, streams, and comments; different rules apply

in those contexts.

White-space characters (see Table 3.1) separate syntactic constructs such as names

and numbers from each other. All white-space characters are equivalent, except

in comments, strings, and streams. In all other contexts, PDF treats any sequence

of consecutive white-space characters as one character.

CHAPTER 3

Syntax

TABLE 3.1 White-space characters

DECIMAL

HEXADECIMAL

OCTAL

NAME

000

Null (NUL)

011

Tab (HT)

012

Line feed (LF)

014

Form feed (FF)

015

Carriage return (CR)

040

Space (SP)

The carriage return (CR) and line feed (LF) characters, also called newline

characters, are treated as end-of-line

(EOL) markers. The combination of a

carriage return followed immediately by a line feed is treated as one EOL marker.

For the most part, EOL markers are treated the same as any other white-space

characters. However, sometimes an EOL marker is required or recommended—

that is, the following token must appear at the beginning of a line.

Note: The examples in this book illustrate a recommended convention for arranging

tokens into lines. However, the examples’ use of white space for indentation is purely

for clarity of exposition and is not recommended for practical use.

The delimiter characters (, ), <, >, [, ], {, }, /, and % are special. They delimit

syntactic entities such as strings, arrays, names, and comments. Any of these

characters terminates the entity preceding it and is not included in the entity.

All characters except the white-space characters and delimiters are referred to as

regular characters. These characters include 8-bit binary characters that are

outside the ASCII character set. A sequence of consecutive regular characters

comprises a single token.

Note: PDF is case-sensitive; corresponding uppercase and lowercase letters are con-

sidered distinct.

SECTION 3.2

Objects

3.1.2

Comments

Any occurrence of the percent sign character (%) outside a string or stream

introduces a comment. The comment consists of all characters between the

percent sign and the end of the line, including regular, delimiter, space, and tab

characters. PDF ignores comments, treating them as if they were single white-

space characters. That is, a comment separates the token preceding it from the

one following it; thus, the PDF fragment

abc% comment { /% ) blah blah blah

123

is syntactically equivalent to just the tokens abc and 123.

Comments (other than the %PDF−n.m and %%EOF comments described in

Section

3.4,

“File Structure”) have no semantics. They are not necessarily

preserved by applications that edit PDF files (see implementation note 2 in

Appendix H). In particular, there is no PDF equivalent of the PostScript

document structuring conventions (DSC).

3.2

Objects

PDF supports eight basic types of objects:

• Boolean values

• Integer and real numbers

• Strings

• Names

• Arrays

• Dictionaries

• Streams

• The null object

Objects may be labeled so that they can be referred to by other objects. A labeled

object is called an indirect object.

CHAPTER 3

Syntax

The following sections describe each object type, as well as how to create and

refer to indirect objects.

3.2.1

Boolean Objects

PDF provides boolean objects identified by the keywords true and false. Boolean

objects can be used as the values of array elements and dictionary entries, and can

also occur in PostScript calculator functions as the results of boolean and

relational operators and as operands to the conditional operators if and ifelse (see

Section 3.9.4, “Type 4 (PostScript Calculator) Functions”).

3.2.2

Numeric Objects

PDF provides two types of numeric objects: integer and real. Integer objects rep-

resent mathematical integers within a certain interval centered at 0. Real objects

approximate mathematical real numbers, but with limited range and precision;

they are typically represented in fixed-point form rather than floating-point

form. The range and precision of numbers are limited by the internal

representations used in the computer on which the PDF consumer application is

running; Appendix C gives these limits for typical implementations.

An integer is written as one or more decimal digits optionally preceded by a sign:

123

43445

+17

−98

The value is interpreted as a signed decimal integer and is converted to an integer

object. If it exceeds the implementation limit for integers, it is converted to a real

object.

A real value is written as one or more decimal digits with an optional sign and a

leading, trailing, or embedded period (decimal point):

34.5

−3.62

+123.6

−.002

0.0

The value is interpreted as a real number and is converted to a real object. If it

exceeds the implementation limit for real numbers, an error occurs.

Note: PDF does not support the PostScript syntax for numbers with nondecimal

radices (such as 16#FFFE) or in exponential format (such as 6.02E23).

SECTION 3.2

Objects

Throughout this book, the term number refers to an object whose type may be

either integer or real. Wherever a real number is expected, an integer may be used

instead and is automatically converted to an equivalent real value. For example, it

is not necessary to write the number 1.0 in real format; the integer 1 is sufficient.

3.2.3

String Objects

A string object consists of a series of bytes—unsigned integer values in the range 0

to 255. String objects are not integer objects, but are stored in a more compact

format. The length of a string may be subject to implementation limits; see

Appendix C.

String objects can be written in two ways:

• As a sequence of literal characters enclosed in parentheses ( ); see “Literal

Strings,” below”

• As hexadecimal data enclosed in angle brackets < >; see “Hexadecimal Strings”

on page 56

This section describes only the basic syntax for writing a string as a sequence of

bytes. Strings can be used for many purposes and can be formatted in a variety of

ways. When a string is used for a specific purpose (to represent a date, for ex-

ample), it is useful to have a standard format for that purpose (see Section 3.8.3,

“Dates”). Such formats are merely conventions for interpreting the contents of a

string and are not separate object types. The use of a particular format is

described with the definition of the string object that uses that format.

Section

3.8.1,

“String Types” describes the encoding schemes used for the

contents of string objects.

Literal Strings

A literal string is written as an arbitrary number of characters enclosed in

parentheses. Any characters may appear in a string except unbalanced

parentheses and the backslash, which must be treated specially. Balanced pairs of

parentheses within a string require no special treatment.

CHAPTER 3

Syntax

The following are valid literal strings:

( This is a string )

( Strings may contain newlines

and such . )

( Strings may contain balanced parentheses ( ) and

special characters ( * ! & } ^ % and so on ) . )

( The following is an empty string . )

( )

( It has zero ( 0 ) length . )

Within a literal string, the backslash (\) is used as an escape character for various

purposes, such as to include newline characters, nonprinting ASCII characters,

unbalanced parentheses, or the backslash character itself in the string. The

character immediately following the backslash determines its precise

interpretation (see Table 3.2). If the character following the backslash is not one

of those shown in the table, the backslash is ignored.

TABLE 3.2 Escape sequences in literal strings

SEQUENCE

MEANING

Line feed (LF)

Carriage return (CR)

Horizontal tab (HT)

Backspace (BS)

Form feed (FF)

Left parenthesis

Right parenthesis

Backslash

\ddd

Character code ddd (octal)

If a string is too long to be conveniently placed on a single line, it may be split

across multiple lines by using the backslash character at the end of a line to

SECTION 3.2

Objects

indicate that the string continues on the following line. The backslash and the

end-of-line marker following it are not considered part of the string. For example:

( These \

two strings \

are the same . )

( These two strings are the same . )

If an end-of-line marker appears within a literal string without a preceding

backslash, the result is equivalent to \n (regardless of whether the end-of-line

marker was a carriage return, a line feed, or both). For example:

( This string has an end−of−line at the end of it .

)

( So does this one .\n )

The \ddd escape sequence provides a way to represent characters outside the

printable ASCII character set. For example:

( This string contains \245two octal characters\307 . )

The number ddd may consist of one, two, or three octal digits, with high-order

overflow ignored. It is required that three octal digits be used, with leading zeros

as needed, if the next character of the string is also a digit. For example, the literal

( \0053 )

denotes a string containing two characters, \005 (Control-E) followed by the digit

3, whereas both

( \053 )

and

( \53 )

denote strings containing the single character \053, a plus sign (+).

This notation provides a way to specify characters outside the 7-bit ASCII

character set by using ASCII characters only. However, any 8-bit value may

appear in a string. In particular, when a document is encrypted (see Section 3.5,

“Encryption”), all of its strings are encrypted and often contain arbitrary 8-bit

CHAPTER 3

Syntax

values. Note that the backslash character is still required as an escape to specify

unbalanced parentheses or the backslash character itself.

Hexadecimal Strings

Strings may also be written in hexadecimal form, which is useful for including

arbitrary binary data in a PDF file. A hexadecimal string is written as a sequence

of hexadecimal digits (0-9 and either A-F or a-f) enclosed within angle brackets

(< and >):

< 4E6F762073686D6F7A206B6120706F702E >

Each pair of hexadecimal digits defines one byte of the string. White-space

characters (such as space, tab, carriage return, line feed, and form feed) are

ignored.

If the final digit of a hexadecimal string is missing—that is, if there is an odd

number of digits—the final digit is assumed to be 0. For example:

< 901FA3 >

is a 3-byte string consisting of the characters whose hexadecimal codes are 90, 1F,

and A3, but

< 901FA >

is a 3-byte string containing the characters whose hexadecimal codes are 90, 1F,

and A0.

3.2.4

Name Objects

A name object is an atomic symbol uniquely defined by a sequence of characters.

Uniquely defined means that any two name objects made up of the same sequence

of characters are identically the same object. Atomic means that a name has no

internal structure; although it is defined by a sequence of characters, those

characters are not considered elements of the name.

A slash character (/) introduces a name. The slash is not part of the name but is a

prefix indicating that the following sequence of characters constitutes a name.

There can be no white-space characters between the slash and the first character

SECTION 3.2

Objects

in the name. The name may include any regular characters, but not delimiter or

white-space characters (see Section 3.1, “Lexical Conventions”). Uppercase and

lowercase letters are considered distinct: /A and /a are different names. The

following examples are valid literal names:

/Name1

/ASomewhatLongerName

/A;Name_With−Various***Characters?

/1 . 2

/$$

/@pattern

/. notdef

Note: The token / (a slash followed by no regular characters) is a valid name.

Beginning with PDF 1.2, any character except null (character code 0) may be

included in a name by writing its 2-digit hexadecimal code, preceded by the

number sign character (#); see implementation notes 3 and 4 in Appendix H.

This syntax is required to represent any of the delimiter or white-space characters

or the number sign character itself; it is recommended but not required for

characters whose codes are outside the range 33 (!) to 126 (~). The examples

shown in Table 3.3 are valid literal names in PDF 1.2 and later.

TABLE 3.3 Examples of literal names using the # character

LITERAL NAME

RESULT

/Adobe#20Green

Adobe Green

/PANTONE#205757#20CV

PANTONE 5757 CV

/paired#28#29parentheses

paired( )parentheses

/The_Key_of_F#23_Minor

The_Key_of_F#_Minor

/A#42

The length of a name is subject to an implementation limit; see Appendix C. The

limit applies to the number of characters in the name’s internal representation.

For example, the name /A#20B has four characters (/, A, space, B), not six.

As stated above, name objects are treated as atomic symbols within a PDF file.

Ordinarily, the bytes making up the name are never treated as text to be presented

to a human user or to an application external to a PDF consumer. However,

CHAPTER 3

Syntax

occasionally the need arises to treat a name object as text, such as one that

represents a font name (see the BaseFont entry in Table 5.8 on page 413) or a

structure type (see Section 10.6.2, “Structure Types”).

In such situations, it is recommended that the sequence of bytes (after expansion

of # sequences, if any) be interpreted according to UTF-8, a variable-length byte-

encoded representation of Unicode in which the printable ASCII characters have

the same representations as in ASCII. This enables a name object to represent text

in any natural language, subject to the implementation limit on the length of a

name. (See implementation note 5 in Appendix H.)

Note: PDF does not prescribe what UTF-8 sequence to choose for representing any

given piece of externally specified text as a name object. In some cases, multiple

UTF-8 sequences could represent the same logical text. Name objects defined by dif-

ferent sequences of bytes constitute distinct name objects in PDF, even though the

UTF-8 sequences might have identical external interpretations.

In PDF, name objects always begin with the slash character (/), unlike keywords

such as true, false, and obj. This book follows a typographic convention of

writing names without the leading slash when they appear in running text and

tables. For example, Type and FullScreen denote names that would actually be

written in a PDF file (and in code examples in this book) as /Type and /FullScreen.

3.2.5

Array Objects

An array object is a one-dimensional collection of objects arranged sequentially.

Unlike arrays in many other computer languages, PDF arrays may be hetero-

geneous; that is, an array’s elements may be any combination of numbers, strings,

dictionaries, or any other objects, including other arrays. The number of

elements in an array is subject to an implementation limit; see Appendix C.

An array is written as a sequence of objects enclosed in square brackets ([ and ]):

[ 549 3.14 false

( Ralph )

/SomeName ]

PDF directly supports only one-dimensional arrays. Arrays of higher dimension

can be constructed by using arrays as elements of arrays, nested to any depth.

SECTION 3.2

Objects

3.2.6

Dictionary Objects

A dictionary object is an associative table containing pairs of objects, known as

the dictionary’s entries. The first element of each entry is the key and the second

element is the value. The key must be a name (unlike dictionary keys in

PostScript, which may be objects of any type). The value can be any kind of

object, including another dictionary. A dictionary entry whose value is null (see

Section 3.2.8, “Null Object”) is equivalent to an absent entry. (This differs from

PostScript, where null behaves like any other object as the value of a dictionary

entry.) The number of entries in a dictionary is subject to an implementation

limit; see Appendix C.

Note: No two entries in the same dictionary should have the same key. If a key does

appear more than once, its value is undefined.

A dictionary is written as a sequence of key-value pairs enclosed in double angle

brackets (<<… >>). For example:

<< /Type /Example

/Subtype /DictionaryExample

/Version 0 . 01

/IntegerItem 12

/StringItem ( a string )

/Subdictionary << /Item1 0 . 4

/Item2 true

/LastItem ( not ! )

/VeryLastItem ( OK )

Note: Do not confuse the double angle brackets with single angle brackets (< and >),

which delimit a hexadecimal string (see “Hexadecimal Strings” on page 56).

Dictionary objects are the main building blocks of a PDF document. They are

commonly used to collect and tie together the attributes of a complex object, such

as a font or a page of the document, with each entry in the dictionary specifying

the name and value of an attribute. By convention, the Type entry of such a

dictionary identifies the type of object the dictionary describes. In some cases, a

Subtype entry (sometimes abbreviated S) is used to further identify a specialized

subcategory of the general type. The value of the Type or Subtype entry is always

CHAPTER 3

Syntax

a name. For example, in a font dictionary, the value of the Type entry is always

Font, whereas that of the Subtype entry may be Type1, TrueType, or one of

several other values.

The value of the Type entry can almost always be inferred from context. The

operand of the Tf operator, for example, must be a font object; therefore, the Type

entry in a font dictionary serves primarily as documentation and as information

for error checking. The Type entry is not required unless so stated in its

description; however, if the entry is present, it must have the correct value. In

addition, the value of the Type entry in any dictionary, even in private data, must

be either a name defined in this book or a registered name; see Appendix E for

details.

3.2.7

Stream Objects

A stream object, like a string object, is a sequence of bytes. However, a PDF

application can read a stream incrementally, while a string must be read in its

entirety. Furthermore, a stream can be of unlimited length, whereas a string is

subject to an implementation limit. For this reason, objects with potentially large

amounts of data, such as images and page descriptions, are represented as

streams.

Note: As with strings, this section describes only the syntax for writing a stream as a

sequence of bytes. What those bytes represent is determined by the context in which

the stream is referenced.

A stream consists of a dictionary followed by zero or more bytes bracketed

between the keywords stream and endstream:

dictionary

stream

… Zero or more bytes…

endstream

All streams must be indirect objects (see Section 3.2.9, “Indirect Objects”) and

the stream dictionary must be a direct object. The keyword stream that follows

the stream dictionary should be followed by an end-of-line marker consisting of

either a carriage return and a line feed or just a line feed, and not by a carriage

SECTION 3.2

Objects

return alone. The sequence of bytes that make up a stream lie between the stream

and endstream keywords; the stream dictionary specifies the exact number of

bytes. It is recommended that there be an end-of-line marker after the data and

before endstream; this marker is not included in the stream length.

Alternatively, beginning with PDF 1.2, the bytes may be contained in an external

file, in which case the stream dictionary specifies the file, and any bytes between

stream and endstream are ignored. (See implementation note 6 in Appendix H.)

Note: Without the restriction against following the keyword stream by a carriage re-

turn alone, it would be impossible to differentiate a stream that uses carriage return

as its end-of-line marker and has a line feed as its first byte of data from one that

uses a carriage return-line feed sequence to denote end-of-line.

Table 3.4 lists the entries common to all stream dictionaries; certain types of

streams may have additional dictionary entries, as indicated where those streams

are described. The optional entries regarding filters for the stream indicate

whether and how the data in the stream must be transformed (decoded) before it

is used. Filters are described further in Section 3.3, “Filters.”

Stream Extent

Every stream dictionary has a Length entry that indicates how many bytes of the

PDF file are used for the stream’s data. (If the stream has a filter, Length is the

number of bytes of encoded data.) In addition, most filters are defined so that the

data is self-limiting; that is, they use an encoding scheme in which an explicit

end-of-data (EOD) marker delimits the extent of the data. Finally, streams are

used to represent many objects from whose attributes a length can be inferred. All

of these constraints must be consistent.

For example, an image with 10 rows and 20 columns, using a single color

component and 8 bits per component, requires exactly 200 bytes of image data. If

the stream uses a filter, there must be enough bytes of encoded data in the PDF

file to produce those 200 bytes. An error occurs if Length is too small, if an

explicit EOD marker occurs too soon, or if the decoded data does not contain 200

bytes.

It is also an error if the stream contains too much data, with the exception that

there may be an extra end-of-line marker in the PDF file before the keyword

endstream.

CHAPTER 3

Syntax

TABLE 3.4

Entries common to all stream dictionaries

KEY

TYPE

VALUE

Length

integer

(Required) The number of bytes from the beginning of the line fol-

lowing the keyword stream to the last byte just before the keyword

endstream. (There may be an additional EOL marker, preceding

endstream, that is not included in the count and is not logically part

of the stream data.) See “Stream Extent,” above, for further discus-

sion.

Filter

name or array

(Optional) The name of a filter to be applied in processing the stream

data found between the keywords stream and endstream, or an array

of such names. Multiple filters should be specified in the order in

which they are to be applied.

DecodeParms

dictionary or array

(Optional) A parameter dictionary or an array of such dictionaries,

used by the filters specified by Filter. If there is only one filter and that

filter has parameters, DecodeParms must be set to the filter’s parame-

ter dictionary unless all the filter’s parameters have their default

values, in which case the DecodeParms entry may be omitted. If there

are multiple filters and any of the filters has parameters set to non-

default values, DecodeParms must be an array with one entry for

each filter: either the parameter dictionary for that filter, or the null

object if that filter has no parameters (or if all of its parameters have

their default values). If none of the filters have parameters, or if all

their parameters have default values, the DecodeParms entry may be

omitted. (See implementation note 7 in Appendix H.)

file specification

(Optional; PDF 1.2) The file containing the stream data. If this entry

is present, the bytes between stream and endstream are ignored, the

filters are specified by FFilter rather than Filter, and the filter parame-

ters are specified by FDecodeParms rather than DecodeParms. How-

ever, the Length entry should still specify the number of those bytes.

(Usually, there are no bytes and Length is 0.) (See implementation

note 46 in Appendix H.)

FFilter

name or array

(Optional; PDF 1.2) The name of a filter to be applied in processing

the data found in the stream’s external file, or an array of such names.

The same rules apply as for Filter.

FDecodeParms

dictionary or array

(Optional; PDF 1.2) A parameter dictionary, or an array of such dic-

tionaries, used by the filters specified by FFilter. The same rules apply

as for DecodeParms.

SECTION 3.2

Objects

KEY

TYPE

VALUE

integer

(Optional; PDF 1.5) A non-negative integer representing the number

of bytes in the decoded (defiltered) stream. It can be used to deter-

mine, for example, whether enough disk space is available to write a

stream to a file.

This value should be considered a hint only; for some stream filters, it

may not be possible to determine this value precisely.

3.2.8

Null Object

The null object has a type and value that are unequal to those of any other object.

There is only one object of type null, denoted by the keyword null. An indirect

object reference (see Section 3.2.9, “Indirect Objects”) to a nonexistent object is

treated the same as a null object. Specifying the null object as the value of a

dictionary entry (Section 3.2.6, “Dictionary Objects”) is equivalent to omitting

the entry entirely.

3.2.9

Indirect Objects

Any object in a PDF file may be labeled as an indirect object. This gives the object

a unique object identifier by which other objects can refer to it (for example, as an

element of an array or as the value of a dictionary entry). The object identifier

consists of two parts:

• A positive integer object number. Indirect objects are often numbered sequen-

tially within a PDF file, but this is not required; object numbers may be

assigned in any arbitrary order.

• A non-negative integer generation number. In a newly created file, all indirect

objects have generation numbers of 0. Nonzero generation numbers may be in-

troduced when the file is later updated; see Sections 3.4.3, “Cross-Reference

Table,” and 3.4.5, “Incremental Updates.”

Together, the combination of an object number and a generation number

uniquely identifies an indirect object. The object retains the same object number

and generation number throughout its existence, even if its value is modified.

CHAPTER 3

Syntax

The definition of an indirect object in a PDF file consists of its object number and

generation number, followed by the value of the object bracketed between the

keywords obj and endobj. For example, the definition

12 0 obj

( Brillig )

endobj

defines an indirect string object with an object number of 12, a generation

number of 0, and the value Brillig.

The object can be referred to from elsewhere in the file by an indirect reference

consisting of the object number, the generation number, and the keyword R:

12 0 R

Beginning with PDF 1.5, indirect objects may reside in object streams (see

Section 3.4.6, “Object Streams”). They are referred to in the same way; however,

their definition does not include the keywords obj and endobj.

An indirect reference to an undefined object is not an error; it is simply treated as

a reference to the null object. For example, if a file contains the indirect reference

17 0 R but does not contain the corresponding definition

17 0 obj

…

endobj

then the indirect reference is considered to refer to the null object.

Note: In the data structures that make up a PDF document, certain values are re-

quired to be specified as indirect object references. Except where this is explicitly

called out, any object (other than a stream) may be specified either directly or as an

indirect object reference; the semantics are entirely equivalent. Note in particular

that content streams, which define the visible contents of the document, may not

contain indirect references (see Section 3.7.1, “Content Streams”). Also, see imple-

mentation note 8 in Appendix H.

Example 3.1 shows the use of an indirect object to specify the length of a stream.

The value of the stream’s Length entry is an integer object that follows the stream

SECTION 3.3

Filters

in the file. This allows applications that generate PDF in a single pass to defer

specifying the stream’s length until after its contents have been generated.

Example 3.1

7 0 obj

<< /Length 8 0 R >>

% An indirect reference to object 8

stream

/F1 12 Tf

72 712 Td

( A stream with an indirect length ) Tj

endstream

endobj

8 0 obj

% The length of the preceding stream

endobj

3.3

Filters

Stream filters are introduced in Section 3.2.7, “Stream Objects.” A filter is an

optional part of the specification of a stream, indicating how the data in the

stream must be decoded before it is used. For example, if a stream has an

ASCIIHexDecode filter, an application reading the data in that stream will

transform the ASCII hexadecimal-encoded data in the stream into binary data.

An application program that produces a PDF file can encode certain information

(for example, data for sampled images) to compress it or to convert it to a port-

able ASCII representation. Then an application that reads (consumes) the PDF

file can invoke the corresponding decoding filter to convert the information back

to its original form.

The filter or filters for a stream are specified by the Filter entry in the stream’s

dictionary (or the FFilter entry if the stream is external). Filters can be cascaded

to form a pipeline that passes the stream through two or more decoding

transformations in sequence. For example, data encoded using LZW and ASCII

base-85 encoding (in that order) can be decoded using the following entry in the

stream dictionary:

/Filter

[ /ASCII85Decode /LZWDecode ]

CHAPTER 3

Syntax

Some filters may take parameters to control how they operate. These optional

parameters are specified by the DecodeParms entry in the stream’s dictionary (or

the FDecodeParms entry if the stream is external).

PDF supports a standard set of filters that fall into two main categories:

• ASCII filters enable decoding of arbitrary 8-bit binary data that has been en-

coded as ASCII text. (See Section 3.1, “Lexical Conventions,” for an explanation

of why this type of encoding might be useful.) Note that ASCII filters serve no

useful purpose in a PDF file that is encrypted; see Section 3.5, “Encryption.”

• Decompression filters enable decoding of data that has been compressed. The

compressed data is always in 8-bit binary format, even if the original data is

ASCII text. (Compression is particularly valuable for large sampled images,

since it reduces storage requirements and transmission time. Some types of

compression are lossy, meaning that some data is lost during the encoding, re-

sulting in a loss of quality when the data is decompressed. Compression in

which no loss of data occurs is called lossless.)

The standard filters are summarized in Table 3.5, which also indicates whether

they accept any optional parameters. The following sections describe these filters

and their parameters

(if any) in greater detail, including specifications of

encoding algorithms for some filters. (See also implementation notes 9 and 10 in

Appendix H.)

Example 3.2 shows a stream, containing the marking instructions for a page, that

was compressed using the LZW compression method and then encoded in ASCII

base-85 representation. Example

3.3 shows the same stream without any

encoding.

(The stream’s contents are explained in Section

3.7.1,

“Content

Streams,” and the operators used there are further described in Chapter 5.)

SECTION 3.3

Filters

TABLE 3.5 Standard filters

FILTER NAME

PARAMETERS?

DESCRIPTION

ASCIIHexDecode

Decodes data encoded in an ASCII hexadecimal representation,

reproducing the original binary data.

ASCII85Decode

Decodes data encoded in an ASCII base-85 representation, repro-

ducing the original binary data.

LZWDecode

yes

Decompresses data encoded using the LZW (Lempel-Ziv-Welch)

adaptive compression method, reproducing the original text or bin-

ary data.

FlateDecode

yes

(PDF 1.2) Decompresses data encoded using the zlib/deflate com-

pression method, reproducing the original text or binary data.

RunLengthDecode

Decompresses data encoded using a byte-oriented run-length encod-

ing algorithm, reproducing the original text or binary data (typically

monochrome image data, or any data that contains frequent long

runs of a single byte value).

CCITTFaxDecode

yes

Decompresses data encoded using the CCITT facsimile standard,

reproducing the original data (typically monochrome image data at 1

bit per pixel).

JBIG2Decode

yes

(PDF 1.4) Decompresses data encoded using the JBIG2 standard,

reproducing the original monochrome (1 bit per pixel) image data

(or an approximation of that data).

DCTDecode

yes

Decompresses data encoded using a DCT (discrete cosine transform)

technique based on the JPEG standard, reproducing image sample

data that approximates the original data.

JPXDecode

(PDF 1.5) Decompresses data encoded using the wavelet-based

JPEG2000 standard, reproducing the original image data.

Crypt

yes

(PDF 1.5) Decrypts data encrypted by a security handler, reproduc-

ing the original data as it was before encryption.

CHAPTER 3

Syntax

Example 3.2

1 0 obj

<< /Length 534

/Filter

[ /ASCII85Decode /LZWDecode ]

stream

J..)6T`?p&<!J9%_[umg"B7/Z7KNXbN'S+,*Q/&"OLT'F

LIDK#!n`$"<Atdi`\Vn%b%)&'cA*VnK\CJY(sF>c!Jnl@

RM]WM;jjH6Gnc75idkL5]+cPZKEBPWdR>FF(kj1_R%W_d

&/jS!;iuad7h?[L−F$+]]0A3Ck*$I0KZ?;<)CJtqi65Xb

Vc3\n5ua:Q/=0$W<#N3U;H,MQKqfg1?:lUpR;6oN[C2E4

ZNr8Udn.'p+?#X+1>0Kuk$bCDF/(3fL5]Oq)^kJZ!C2H1

'TO]Rl?Q:&'<5&iP!$Rq;BXRecDN[IJB`,)o8XJOSJ9sD

S]hQ;Rj@!ND)bD_q&C\g:inYC%)&u#:u,M6Bm%IY!Kb1+

":aAa'S`ViJglLb8<W9k6Yl\\0McJQkDeLWdPN?9A'jX*

al>iG1p&i;eVoK&juJHs9%;Xomop"5KatWRT"JQ#qYuL,

JD?M$0QP)lKn06l1apKDC@\qJ4B!!(5m+j.7F790m(Vj8

8l8Q:_CZ(Gm1%X\N1&u!FKHMB~>

endstream

endobj

Example 3.3

1 0 obj

<< /Length 568 >>

stream

2 J

/F1 12 Tf

0 Tc

0 Tw

72.5 712 TD

[ ( Unencoded streams can be read easily ) 65 ( , ) ] TJ

0 −14 TD

[ ( b )

20 ( ut generally tak ) 10 ( e more space than \311 ) ] TJ

T* ( encoded streams . ) Tj

0 −28 TD

[ ( Se )

25 ( v ) 15 ( eral encoding methods are a ) 20 ( v) 25 ( ailable in PDF ) 80

( . ) ]

0 −14 TD

( Some are used for compression and others simply ) Tj

T* [ ( to represent binary data in an ) 55 ( ASCII format . ) ] TJ

T* ( Some of the compression encoding methods are \

suitable ) Tj

SECTION 3.3

Filters

T* ( for both data and images , while others are \

suitable only ) Tj

T* ( for continuous−tone images . ) Tj

endstream

endobj

3.3.1

ASCIIHexDecode Filter

The ASCIIHexDecode filter decodes data that has been encoded in ASCII

hexadecimal form. ASCII hexadecimal encoding and ASCII base-85 encoding

(described in the next section) convert binary data, such as image data, to 7-bit

ASCII characters. In general, ASCII base-85 encoding is preferred to ASCII

hexadecimal encoding because it is more compact: it expands the data by a factor

of 4 : 5, compared with 1 : 2 for ASCII hexadecimal encoding.

The ASCIIHexDecode filter produces one byte of binary data for each pair of

ASCII hexadecimal digits (0-9 and A-F or a-f). All white-space characters (see

Section 3.1, “Lexical Conventions”) are ignored. A right angle bracket character

(>) indicates EOD. Any other characters cause an error. If the filter encounters

the EOD marker after reading an odd number of hexadecimal digits, it behaves as

if a 0 followed the last digit.

3.3.2

ASCII85Decode Filter

The ASCII85Decode filter decodes data that has been encoded in ASCII base-85

encoding and produces binary data. The following paragraphs describe the

process for encoding binary data in ASCII base-85; the ASCII85Decode filter

reverses this process.

The ASCII base-85 encoding uses the characters ! through u and the character z,

with the 2-character sequence ~> as its EOD marker. The ASCII85Decode filter

ignores all white-space characters (see Section 3.1, “Lexical Conventions”). Any

other characters, and any character sequences that represent impossible

combinations in the ASCII base-85 encoding, cause an error.

CHAPTER 3

Syntax

Specifically, ASCII base-85 encoding produces 5 ASCII characters for every 4

bytes of binary data. Each group of 4 binary input bytes, (b₁ b₂ b₃ b₄ ), is converted

to a group of 5 output bytes, (c₁ c₂ c₃ c₄ c₅ ), using the relation

(

b₁

256³

)

(

b₂

256²

)

(

b₃

256¹

)+ b₄

(

c₁

85⁴

)

(

c₂

85³

)

(

c₃

85²

)

(

c₄

85¹

)+ c₅

In other words, 4 bytes of binary data are interpreted as a base-256 number and

then converted to a base-85 number. The five bytes of the base-85 number are

then converted to ASCII characters by adding 33 (the ASCII code for the

character ! ) to each. The resulting encoded data contains only printable ASCII

characters with codes in the range 33 ( ! ) to 117 (u). As a special case, if all five

bytes are 0, they are represented by the character with code 122 (z) instead of by

five exclamation points ( ! ! ! ! ! ).

If the length of the binary data to be encoded is not a multiple of 4 bytes, the last,

partial group of 4 is used to produce a last, partial group of 5 output characters.

Given n (1, 2, or 3) bytes of binary data, the encoder first appends 4 − n zero bytes

to make a complete group of 4. It then encodes this group in the usual way, but

without applying the special z case. Finally, it writes only the first n + 1 characters

of the resulting group of 5. These characters are immediately followed by the ~>

EOD marker.

The following conditions

(which never occur in a correctly encoded byte

sequence) cause errors during decoding:

• The value represented by a group of 5 characters is greater than 2³² − 1.

• A z character occurs in the middle of a group.

• A final partial group contains only one character.

SECTION 3.3

Filters

3.3.3

LZWDecode and FlateDecode Filters

The LZWDecode and (in PDF 1.2) FlateDecode filters have much in common and

are discussed together in this section. They decode data that has been encoded

using the LZW or Flate data compression method, respectively:

• LZW (Lempel-Ziv-Welch) is a variable-length, adaptive compression method

that has been adopted as one of the standard compression methods in the Tag

Image File Format (TIFF) standard. Details on LZW encoding follow in the

next section.

• The Flate method is based on the public-domain zlib/deflate compression

method, which is a variable-length Lempel-Ziv adaptive compression method

cascaded with adaptive Huffman coding. It is fully defined in Internet RFCs

1950, ZLIB Compressed Data Format Specification, and 1951, DEFLATE Com-

pressed Data Format Specification (see the Bibliography).

Both of these methods compress either binary data or ASCII text but (like all

compression methods) always produce binary data, even if the original data was

text.

The LZW and Flate compression methods can discover and exploit many

patterns in the input data, whether the data is text or images. As described later,

both filters support optional transformation by a predictor function, which

improves the compression of sampled image data. Because of its cascaded

adaptive Huffman coding, Flate-encoded output is usually much more compact

than LZW-encoded output for the same input. Flate and LZW decoding speeds

are comparable, but Flate encoding is considerably slower than LZW encoding.

Usually, both Flate and LZW encodings compress their input substantially.

However, in the worst case (in which no pair of adjacent characters appears

twice), Flate encoding expands its input by no more than 11 bytes or a factor of

1.003 (whichever is larger), plus the effects of algorithm tags added by PNG

predictors. For LZW encoding, the best case (all zeros) provides a compression

approaching 1365 : 1 for long files, but the worst-case expansion is at least a factor

of 1.125, which can increase to nearly 1.5 in some implementations, plus the

effects of PNG tags as with Flate encoding.

CHAPTER 3

Syntax

Details of LZW Encoding

Data encoded using the LZW compression method consists of a sequence of

codes that are 9 to 12 bits long. Each code represents a single character of input

data (0-255), a clear-table marker (256), an EOD marker (257), or a table entry

representing a multiple-character sequence that has been encountered previously

in the input (258 or greater).

Initially, the code length is 9 bits and the LZW table contains only entries for the

258 fixed codes. As encoding proceeds, entries are appended to the table, asso-

ciating new codes with longer and longer sequences of input characters. The

encoder and the decoder maintain identical copies of this table.

Whenever both the encoder and the decoder independently (but synchronously)

realize that the current code length is no longer sufficient to represent the

number of entries in the table, they increase the number of bits per code by 1. The

first output code that is 10 bits long is the one following the creation of table entry

511, and similarly for 11 (1023) and 12 (2047) bits. Codes are never longer than

12 bits; therefore, entry 4095 is the last entry of the LZW table.

The encoder executes the following sequence of steps to generate each output

code:

1. Accumulate a sequence of one or more input characters matching a sequence

already present in the table. For maximum compression, the encoder looks for

the longest such sequence.

2. Emit the code corresponding to that sequence.

3. Create a new table entry for the first unused code. Its value is the sequence

found in step 1 followed by the next input character.

For example, suppose the input consists of the following sequence of ASCII

character codes:

45 45 45 45 45 65 45 45 45 66

Starting with an empty table, the encoder proceeds as shown in Table 3.6.

SECTION 3.3

Filters

TABLE 3.6 Typical LZW encoding sequence

INPUT

OUTPUT

CODE ADDED

SEQUENCE REPRESENTED

SEQUENCE

CODE

TO TABLE

BY NEW CODE

–

256 (clear-table)

258

45 45

258

259

45 45 45

45 45

258

260

45 45 65

261

65 45

45 45 45

259

262

45 45 45 66

–

257 (EOD)

Codes are packed into a continuous bit stream, high-order bit first. This stream is

then divided into 8-bit bytes, high-order bit first. Thus, codes can straddle byte

boundaries arbitrarily. After the EOD marker (code value 257), any leftover bits

in the final byte are set to 0.

In the example above, all the output codes are 9 bits long; they would pack into

bytes as follows (represented in hexadecimal):

80 0B 60 50 22 0C 0C 85 01

To adapt to changing input sequences, the encoder may at any point issue a clear-

table code, which causes both the encoder and the decoder to restart with initial

tables and a 9-bit code length. By convention, the encoder begins by issuing a

clear-table code. It must issue a clear-table code when the table becomes full; it

may do so sooner.

LZWDecode and FlateDecode Parameters

The LZWDecode and FlateDecode filters accept optional parameters to control

the decoding process. Most of these parameters are related to techniques that

reduce the size of compressed sampled images (rectangular arrays of color values,

described in Section 4.8, “Images”). For example, image data typically changes

very little from sample to sample. Therefore, subtracting the values of adjacent

CHAPTER 3

Syntax

samples (a process called differencing), and encoding the differences rather than

the raw sample values, can reduce the size of the output data. Furthermore, when

the image data contains several color components (red-green-blue or cyan-

magenta-yellow-black) per sample, taking the difference between the values of

corresponding components in adjacent samples, rather than between different

color components in the same sample, often reduces the output data size.

Table 3.7 shows the parameters that can optionally be specified for LZWDecode

and FlateDecode filters. Except where otherwise noted, all values supplied to the

decoding filter for any optional parameters must match those used when the data

was encoded.

TABLE 3.7 Optional parameters for LZWDecode and FlateDecode filters

KEY

TYPE

VALUE

Predictor

integer

A code that selects the predictor algorithm, if any. If the value of this entry

is 1, the filter assumes that the normal algorithm was used to encode the data,

without prediction. If the value is greater than 1, the filter assumes that the

data was differenced before being encoded, and Predictor selects the predic-

tor algorithm. For more information regarding Predictor values greater

than 1, see “LZW and Flate Predictor Functions,” below. Default value: 1.

Colors

integer

(Used only if Predictor is greater than 1) The number of interleaved color com-

ponents per sample. Valid values are 1 to 4 in PDF 1.2 or earlier and 1 or

greater in PDF 1.3 or later. Default value: 1.

BitsPerComponent

integer

(Used only if Predictor is greater than 1) The number of bits used to represent

each color component in a sample. Valid values are 1, 2, 4, 8, and (in PDF 1.5)

16. Default value: 8.

Columns

integer

(Used only if Predictor is greater than 1) The number of samples in each row.

Default value: 1.

EarlyChange

integer

(LZWDecode only) An indication of when to increase the code length. If the

value of this entry is 0, code length increases are postponed as long as pos-

sible. If the value is 1, code length increases occur one code early. This pa-

rameter is included because LZW sample code distributed by some vendors

increases the code length one code earlier than necessary. Default value: 1.

SECTION 3.3

Filters

LZW and Flate Predictor Functions

LZW and Flate encoding compress more compactly if their input data is highly

predictable. One way of increasing the predictability of many continuous-tone

sampled images is to replace each sample with the difference between that sample

and a predictor function applied to earlier neighboring samples. If the predictor

function works well, the postprediction data clusters toward 0.

Two groups of predictor functions are supported. The first, the TIFF group,

consists of the single function that is Predictor 2 in the TIFF standard. (In the

TIFF standard, Predictor 2 applies only to LZW compression, but here it applies

to Flate compression as well.) TIFF Predictor

2 predicts that each color

component of a sample is the same as the corresponding color component of the

sample immediately to its left.

The second supported group of predictor functions, the PNG group, consists of

the filters of the World Wide Web Consortium’s Portable Network Graphics

recommendation, documented in Internet RFC 2083, PNG (Portable Network

Graphics) Specification (see the Bibliography). The term predictors is used here

instead of filters to avoid confusion. There are five basic PNG predictor

algorithms (and a sixth that chooses the optimum predictor function separately

for each row):

None

No prediction

Sub

Predicts the same as the sample to the left

Predicts the same as the sample above

Average

Predicts the average of the sample to the left and the sample above

Paeth

A nonlinear function of the sample above, the sample to the left,

and the sample to the upper left

The predictor algorithm to be used, if any, is indicated by the Predictor filter

parameter (see Table 3.7), which can have any of the values listed in Table 3.8.

For LZWDecode and FlateDecode, a Predictor value greater than or equal to 10

merely indicates that a PNG predictor is in use; the specific predictor function

used is explicitly encoded in the incoming data. The value of Predictor supplied

by the decoding filter need not match the value used when the data was encoded

if they are both greater than or equal to 10.

CHAPTER 3

Syntax

TABLE 3.8 Predictor values

VALUE

MEANING

No prediction (the default value)

TIFF Predictor 2

PNG prediction (on encoding, PNG None on all rows)

PNG prediction (on encoding, PNG Sub on all rows)

PNG prediction (on encoding, PNG Up on all rows)

PNG prediction (on encoding, PNG Average on all rows)

PNG prediction (on encoding, PNG Paeth on all rows)

PNG prediction (on encoding, PNG optimum)

The two groups of predictor functions have some commonalities. Both make the

following assumptions:

• Data is presented in order, from the top row to the bottom row and, within a

row, from left to right.

• A row occupies a whole number of bytes, rounded up if necessary.

• Samples and their components are packed into bytes from high-order to low-

order bits.

• All color components of samples outside the image (which are necessary for

predictions near the boundaries) are 0.

The predictor function groups also differ in significant ways:

• The postprediction data for each PNG-predicted row begins with an explicit

algorithm tag; therefore, different rows can be predicted with different algo-

rithms to improve compression. TIFF Predictor 2 has no such identifier; the

same algorithm applies to all rows.

• The TIFF function group predicts each color component from the prior in-

stance of that component, taking into account the number of bits per com-

ponent and components per sample. In contrast, the PNG function group

predicts each byte of data as a function of the corresponding byte of one or

SECTION 3.3

Filters

more previous image samples, regardless of whether there are multiple color

components in a byte or whether a single color component spans multiple

bytes. This can yield significantly better speed at the cost of somewhat worse

compression.

3.3.4

RunLengthDecode Filter

The RunLengthDecode filter decodes data that has been encoded in a simple

byte-oriented format based on run length. The encoded data is a sequence of

runs, where each run consists of a length byte followed by 1 to 128 bytes of data. If

the length byte is in the range 0 to 127, the following length + 1 (1 to 128) bytes

are copied literally during decompression. If length is in the range 129 to 255, the

following single byte is to be copied

257 − length (2 to 128) times during

decompression. A length value of 128 denotes EOD.

The compression achieved by run-length encoding depends on the input data. In

the best case (all zeros), a compression of approximately 64 : 1 is achieved for long

files. The worst case (the hexadecimal sequence 00 alternating with FF) results in

an expansion of 127 : 128.

3.3.5

CCITTFaxDecode Filter

The CCITTFaxDecode filter decodes image data that has been encoded using

either Group 3 or Group 4 CCITT facsimile (fax) encoding. CCITT encoding is

designed to achieve efficient compression of monochrome (1 bit per pixel) image

data at relatively low resolutions, and so is useful only for bitmap image data, not

for color images, grayscale images, or general data.

The CCITT encoding standard is defined by the International

Telecommunications Union (ITU), formerly known as the Comité Consultatif

International Téléphonique et Télégraphique

(International Coordinating

Committee for Telephony and Telegraphy). The encoding algorithm is not

described in detail in this book but can be found in ITU Recommendations T.4

and T.6

(see the Bibliography). For historical reasons, we refer to these

documents as the CCITT standard.

CHAPTER 3

Syntax

CCITT encoding is bit-oriented, not byte-oriented. Therefore, in principle,

encoded or decoded data might not end at a byte boundary. This problem is dealt

with in the following ways:

• Unencoded data is treated as complete scan lines, with unused bits inserted at

the end of each scan line to fill out the last byte. This approach is compatible

with the PDF convention for sampled image data.

• Encoded data is ordinarily treated as a continuous, unbroken bit stream. The

EncodedByteAlign parameter (described in Table 3.9) can be used to cause

each encoded scan line to be filled to a byte boundary. Although this is not pre-

scribed by the CCITT standard and fax machines never do this, some software

packages find it convenient to encode data this way.

• When a filter reaches EOD, it always skips to the next byte boundary following

the encoded data.

If the CCITTFaxDecode filter encounters improperly encoded source data, an

error occurs. The filter does not perform any error correction or

resynchronization, except as noted for the DamagedRowsBeforeError parameter

in Table 3.9.

Table 3.9 lists the optional parameters that can be used to control the decoding.

Except where noted otherwise, all values supplied to the decoding filter by any of

these parameters must match those used when the data was encoded.

TABLE 3.9 Optional parameters for the CCITTFaxDecode filter

KEY

TYPE

VALUE

integer

A code identifying the encoding scheme used:

< 0

Pure two-dimensional encoding (Group 4)

Pure one-dimensional encoding (Group 3, 1-D)

> 0

Mixed one- and two-dimensional encoding (Group 3, 2-D),

in which a line encoded one-dimensionally can be followed

by at most K − 1 lines encoded two-dimensionally

The filter distinguishes among negative, zero, and positive values of

K to determine how to interpret the encoded data; however, it does

not distinguish between different positive K values. Default value: 0.

SECTION 3.3

Filters

KEY

TYPE

VALUE

EndOfLine

boolean

A flag indicating whether end-of-line bit patterns are required to be

present in the encoding. The CCITTFaxDecode filter always accepts

end-of-line bit patterns, but requires them only if EndOfLine is true.

Default value: false.

EncodedByteAlign

boolean

A flag indicating whether the filter expects extra 0 bits before each

encoded line so that the line begins on a byte boundary. If true, the

filter skips over encoded bits to begin decoding each line at a byte

boundary. If false, the filter does not expect extra bits in the encod-

ed representation. Default value: false.

Columns

integer

The width of the image in pixels. If the value is not a multiple of 8,

the filter adjusts the width of the unencoded image to the next mul-

tiple of 8 so that each line starts on a byte boundary. Default value:

1728.

Rows

integer

The height of the image in scan lines. If the value is 0 or absent, the

image’s height is not predetermined, and the encoded data must be

terminated by an end-of-block bit pattern or by the end of the fil-

ter’s data. Default value: 0.

EndOfBlock

boolean

A flag indicating whether the filter expects the encoded data to be

terminated by an end-of-block pattern, overriding the Rows param-

eter. If false, the filter stops when it has decoded the number of lines

indicated by Rows or when its data has been exhausted, whichever

occurs first. The end-of-block pattern is the CCITT end-of-facsim-

ile-block (EOFB) or return-to-control (RTC) appropriate for the K

parameter. Default value: true.

BlackIs1

boolean

A flag indicating whether 1 bits are to be interpreted as black pixels

and 0 bits as white pixels, the reverse of the normal PDF convention

for image data. Default value: false.

DamagedRowsBeforeError

integer

The number of damaged rows of data to be tolerated before an error

occurs. This entry applies only if EndOfLine is true and K is non-

negative. Tolerating a damaged row means locating its end in the

encoded data by searching for an EndOfLine pattern and then sub-

stituting decoded data from the previous row if the previous row

was not damaged, or a white scan line if the previous row was also

damaged. Default value: 0.

CHAPTER 3

Syntax

The compression achieved using CCITT encoding depends on the data, as well as

on the value of various optional parameters. For Group 3 one-dimensional

encoding, in the best case (all zeros), each scan line compresses to 4 bytes, and the

compression factor depends on the length of a scan line. If the scan line is 300

bytes long, a compression ratio of approximately 75 : 1 is achieved. The worst case,

an image of alternating ones and zeros, produces an expansion of 2 : 9.

3.3.6

JBIG2Decode Filter

The JBIG2Decode filter (PDF 1.4) decodes monochrome (1 bit per pixel) image

data that has been encoded using JBIG2 encoding. JBIG stands for the Joint Bi-

Level Image Experts Group, a group within the International Organization for

Standardization (ISO) that developed the format. JBIG2 is the second version of a

standard originally released as JBIG1.

JBIG2 encoding, which provides for both lossy and lossless compression, is useful

only for monochrome images, not for color images, grayscale images, or general

data. The algorithms used by the encoder, and the details of the format, are not

described here. A working draft of the JBIG2 specification can be found through

the Web site for the JBIG and JPEG (Joint Photographic Experts Group)

committees at < http://www.jpeg.org >.

In general, JBIG2 provides considerably better compression than the existing

CCITT standard (discussed in Section 3.3.5). The compression it achieves

depends strongly on the nature of the image. Images of pages containing text in

any language compress particularly well, with typical compression ratios of 20:1

to 50:1 for a page full of text. The JBIG2 encoder builds a table of unique symbol

bitmaps found in the image, and other symbols found later in the image are

matched against the table. Matching symbols are replaced by an index into the

table, and symbols that fail to match are added to the table. The table itself is

compressed using other means. This method results in high compression ratios

for documents in which the same symbol is repeated often, as is typical for

images created by scanning text pages. It also results in high compression of white

space in the image, which does not need to be encoded because it contains no

symbols.

While best compression is achieved for images of text, the JBIG2 standard also

includes algorithms for compressing regions of an image that contain dithered

halftone images (for example, photographs).

SECTION 3.3

Filters

The JBIG2 compression method can also be used for encoding multiple images

into a single JBIG2 bit stream. Typically, these images are scanned pages of a

multiple-page document. Since a single table of symbol bitmaps is used to match

symbols across multiple pages, this type of encoding can result in higher

compression ratios than if each of the pages had been individually encoded using

JBIG2.

In general, an image may be specified in PDF as either an image XObject or an

inline image (as described in Section 4.8, “Images”); however, the JBIG2Decode

filter can be applied only to image XObjects.

This filter addresses both single-page and multiple-page JBIG2 bit streams by

representing each JBIG2 page as a PDF image, as follows:

• The filter uses the embedded file organization of JBIG2. (The details of this and

the other types of file organization are provided in an annex of the ISO specifi-

cation.) The optional 2-byte combination (marker) mentioned in the specifica-

tion is not used in PDF. JBIG2 bit streams in random-access organization

should be converted to the embedded file organization. Bit streams in sequen-

tial organization need no reorganization, except for the mappings described

below.

• The JBIG2 file header, end-of-page segments, and end-of-file segment are not

used in PDF. These should be removed before the PDF objects described below

are created.

• The image XObject to which the JBIG2Decode filter is applied contains all seg-

ments that are associated with the JBIG2 page represented by that image; that

is, all segments whose segment page association field contains the page number

of the JBIG2 page represented by the image. In the image XObject, however, the

segment’s page number should always be 1; that is, when each such segment is

written to the XObject, the value of its segment page association field should be

set to 1.

• If the bit stream contains global segments (segments whose segment page asso-

ciation field contains 0), these segments must be placed in a separate PDF

stream, and the filter parameter listed in Table 3.10 should refer to that stream.

The stream can be shared by multiple image XObjects whose JBIG2 encodings

use the same global segments.

CHAPTER 3

Syntax

TABLE 3.10 Optional parameter for the JBIG2Decode filter

KEY

TYPE

VALUE

JBIG2Globals

stream

A stream containing the JBIG2 global (page 0) segments. Global segments

must be placed in this stream even if only a single JBIG2 image XObject re-

fers to it.

Example 3.4 shows an image that was compressed using the JBIG2 compression

method and then encoded in ASCII hexadecimal representation. Since the JBIG2

bit stream contains global segments, these segments are placed in a separate PDF

stream, as indicated by the JBIG2Globals filter parameter.

Example 3.4

5 0 obj

<< /Type /XObject

/Subtype /Image

/Width 52

/Height 66

/ColorSpace /DeviceGray

/BitsPerComponent 1

/Length 224

/Filter

[ /ASCIIHexDecode /JBIG2Decode ]

/DecodeParms [ null << /JBIG2Globals 6 0 R >> ]

stream

000000013000010000001300000034000000420000000000

00000040000000000002062000010000001e000000340000

004200000000000000000200100000000231db51ce51ffac >

endstream

endobj

6 0 obj

<< /Length 126

/Filter

/ASCIIHexDecode

stream

0000000000010000000032000003fffdff02fefefe000000

01000000012ae225aea9a5a538b4d9999c5c8e56ef0f872

7f2b53d4e37ef795cc5506dffac >

endstream

endobj

SECTION 3.3

Filters

The JBIG2 bit stream for this example is as follows:

97 4A 42 32 0D 0A 1A 0A 01 00 00 00 01 00 00 00 00 00 01 00 00 00 00 32

00 00 03 FF FD FF 02 FE FE FE 00 00 00 01 00 00 00 01 2A E2 25 AE A9 A5

A5 38 B4 D9 99 9C 5C 8E 56 EF 0F 87 27 F2 B5 3D 4E 37 EF 79 5C C5 50 6D

FF AC 00 00 00 01 30 00 01 00 00 00 13 00 00 00 34 00 00 00 42 00 00 00

00 00 00 00 00 40 00 00 00 00 00 02 06 20 00 01 00 00 00 1E 00 00 00 34

00 00 00 42 00 00 00 00 00 00 00 00 02 00 10 00 00 00 02 31 DB 51 CE 51

FF AC 00 00 00 03 31 00 01 00 00 00 00 00 00 00 04 33 01 00 00 00 00

This bit stream is made up of the following parts (in the order listed):

The JBIG2 file header

97 4A 42 32 0D 0A 1A 0A 01 00 00 00 01

Since the JBIG2 file header is not used in PDF, this header is not placed in the

JBIG2 stream object and is discarded.

The first JBIG2 segment (segment 0)—in this case, the symbol dictionary seg-

ment

00 00 00 00 00 01 00 00 00 00 32 00 00 03 FF FD FF 02 FE FE FE 00 00 00

01 00 00 00 01 2A E2 25 AE A9 A5 A5 38 B4 D9 99 9C 5C 8E 56 EF 0F 87

27 F2 B5 3D 4E 37 EF 79 5C C5 50 6D FF AC

This is a global segment (segment page association = 0) and so is placed in the

JBIG2Globals stream.

The page information segment

00 00 00 01 30 00 01 00 00 00 13 00 00 00 34 00 00 00 42 00 00 00 00

00 00 00 00 40 00 00

and the immediate text region segment

00 00 00 02 06 20 00 01 00 00 00 1E 00 00 00 34 00 00 00 42 00 00 00

00 00 00 00 00 02 00 10 00 00 00 02 31 DB 51 CE 51 FF AC

These two segments constitute the contents of the JBIG2 page and are placed

in the PDF XObject representing this image.

The end-of-page segment

00 00 00 03 31 00 01 00 00 00 00

and the end-of-file segment

00 00 00 04 33 01 00 00 00 00

Since these segments are not used in PDF, they are discarded.

CHAPTER 3

Syntax

The resulting PDF image object, then, contains the page information segment

and the immediate text region segment and refers to a JBIG2Globals stream that

contains the symbol dictionary segment.

3.3.7

DCTDecode Filter

The DCTDecode filter decodes grayscale or color image data that has been

encoded in the JPEG baseline format. (JPEG stands for the Joint Photographic

Experts Group, a group within the International Organization for

Standardization that developed the format; DCT stands for discrete cosine

transform, the primary technique used in the encoding.)

JPEG encoding is a lossy compression method, designed specifically for

compression of sampled continuous-tone images and not for general data

compression. Data to be encoded using JPEG consists of a stream of image

samples, each consisting of one, two, three, or four color components. The color

component values for a particular sample must appear consecutively. Each

component value occupies an 8-bit byte.

During encoding, several parameters control the algorithm and the information

loss. The values of these parameters, which include the dimensions of the image

and the number of components per sample, are entirely under the control of the

encoder and are stored in the encoded data. DCTDecode generally obtains the

parameter values it requires directly from the encoded data. However, in one

instance, the parameter might not be present in the encoded data but must be

specified in the filter parameter dictionary; see Table 3.11.

The details of the encoding algorithm are not presented here but are in the ISO

specification and in JPEG: Still Image Data Compression Standard, by Pennebaker

and Mitchell (see the Bibliography). Briefly, the JPEG algorithm breaks an image

up into blocks that are 8 samples wide by 8 samples shigh. Each color component

in an image is treated separately. A two-dimensional DCT is performed on each

block. This operation produces 64 coefficients, which are then quantized. Each

coefficient may be quantized with a different step size. It is this quantization that

results in the loss of information in the JPEG algorithm. The quantized coef-

ficients are then compressed.

Была ли эта страница вам полезна?

Да!Нет

8 посетителей считают эту страницу полезной.

PDF Reference sixth edition, Adobe Portable Document Format Version 1.7 (book 1) — page 2

Нет комментариевНе стесняйтесь поделиться с нами вашим ценным мнением.
